Fuji Spray HVLP Spray System T70 and T75G Series Spray Tip
Fuji HVLP Spray System T70 and T75G Series Spray Tip



Each Air Cap Set Sold Separately. Price Reflects Single Size.
Our Price: $61.99

Product Code: FJ5100


Fuji T-Series Tip Sizes*:
#1 - 0.8mm
#2 - 1.0mm
#3 - 1.3mm
#4 - 1.5mm
#5 - 1.8mm
#6 - 2.0mm
#7 - 2.5mm

Qty:
Description


Fits Fuji's T70 and T75G HVLP Spray Guns

Each air cap set sold separately.

Fuji R & D utilized computer Fluid Dynamics programs that yielded data suggesting improvements could be made to the angles and hole sizes in the Aircap. Once samples were made and tested, the Aircaps exceeded all expectations. The High-Efficency Aircaps provide the user with a cleaner spray pattern that results in less overspray and mist in the air.

A cleaner spray pattern amounts to less overspray. Less Overspray = More Savings!

Color Coding of T-Series aircap sizes is used to make aircap selection and changes much easier.
What Fuji has done is reduce the width of the actual fan pattern. If we take a vertical pattern, the height (lets say 9) stays exactly the same, but the width of the H, compared to standard Aircaps is much less. Whats the advantage of a thinner-width fan pattern? Well, as you know, when you spray across a board, as you come off the edge, particles are spraying into the air and adding to the overspray (mist) in the air. But you have to continue holding down the trigger until you finally pass over the edge of the board. You cannot stop at the edge of the board but must follow through past the board. The wider the width of the fan pattern, the longer it takes to pass off the edge of the board. It is this extra width of fan pattern that is adding to the number of airborne particles with each pass. It becomes even more significant when you realize how many times you pass over the edge of a board when spraying a cabinet or piece of furniture. The Fuji High-Efficiency Aircap is an exclusive feature from Fuji.

#1, 0.8mm - Perfect for very fine work. Also good for small surfaces and thinner viscosity fluids. Shading stains/Inks, as well as touch-ups, zinc, dyes water-based finishes. FOR T-SERIES SPRAY GUN ONLY.
#2, 1.0mm - Great for most fine finishing including water-based/borne coatings. Allows for thinner, wet coat to be applied. Automotive enamel and marine finishes. Nitrocellulose lacquers, sealer, cellulose acrylics, synthetics, polyurethane, stains, varnish, and primers. FOR T-SERIES SPRAY GUN ONLY.
#3, 1.3mm - Similar to the #2 but with more coverage. Automotive enamel, airplane and marine finishes. Nitrocellulose lacquers, water-based finishes, varnish, urethanes, enamel, latex for louver doors, trims and cabinets, and oil based paints. FOR T-SERIES SPRAY GUN ONLY.
#4, 1.5mm - Similar to the #3 but requires less thinning. Automotive enamel, airplane and marine finishes. Nitrocellulose lacquers, water-based finishes, varnish, urethanes, enamel, latex for louver doors, trims and cabinets, and oil based paints. FOR T-SERIES SPRAY GUN ONLY.
#5, 1.8mm - Ideal for larger surfaces, and thicker layers. Catalyzed lacquers, primers, varnish, urethanes, enamel, industrial coating (higher viscosity), sealers, polyurethane, oil based paints, epoxy enamels, plastic, adhesives, floor paving paints, latex (walls), splatter paints and multi fleck paints. FOR T-SERIES SPRAY GUN ONLY.
#6, 2.0mm - Similar to the #5 but with more coverage. Ideal for larger surfaces, and thicker layers. Catalyzed lacquers, primers, varnish, urethanes, enamel, industrial coating (higher viscosity), sealers, polyurethane, oil based paints, epoxy enamels, plastic, adhesives, floor paving paints, latex (walls), splatter paints and multi fleck paints. FOR T-SERIES SPRAY GUN ONLY.
#7, 2.5mm - Suitable for even larger areas/walls & ceilings. Ideal for fast coverage. Stone finish, texture coating, industrial primers, latex (walls and ceilings), high viscosity industrial coating and nitrate dope. FOR T-SERIES SPRAY GUN ONLY.

Tip Sizes Sold Individually


California Residents
Warning Cancer and Reproductive Harm - see Prop 65 Warnings
Average Rating: Average Rating: 5 of 5 5 of 5 Total Reviews: 22 Write a review »


  0 of 0 people found the following review helpful:

5 of 5 Hvlp spray system t70 and t75 series spray tip November 11, 2019
Reviewer: Mad drywall and painting from Chico, CA United States
Recently purchased the above items, comes with the 1.3 tip, I also purchased a 1.8 and 2.5, the first couple times I used it, was a little different from what I was used too. After a couple times it became clear, this thing is bad ass. The ease of clean up, the way it sprays, after getting the material thimmed down enough, it was  amazing, I sprayed  a cabin with wooden ceilings and beams, after masking  it off, I was worried about paint, blowing under the tape, or paper, after I was done, I removed the masking paper, not one speck of paint under it, there was also no overspray, anywhere inside the cabin. I would have to say, best investment of the year, also, I did buy the remote, from hd. Its very nice to have, amazing unit, originally purchased to paint a couple cars, but have painted the insides of 4 homes and counting. Thanks paintsprayers plus

Was this review helpful to you?

  0 of 0 people found the following review helpful:

5 of 5 Impressive HVLP Sprayer October 24, 2019
Reviewer: Jerry Jenkins from Maryland, United States
The Fuji T70 sprayer is constructed from high quality parts.  It is easy to disassemble and put back together, cleanup is quick and easy.

Was this review helpful to you?

  0 of 0 people found the following review helpful:

5 of 5 Fuji Spray Tip October 13, 2019
Reviewer: Ted Diehl from Goodyear, AZ United States
Purchased on line and it was fast and easy.  The spray tips are Fuji Tips

Was this review helpful to you?

  0 of 0 people found the following review helpful:

5 of 5 T-70 Spray tips May 19, 2019
Reviewer: J Carter from Eugene, OR United States
Quick, convenient, and very helpful.  I will use them as much as needed.

Was this review helpful to you?

  0 of 0 people found the following review helpful:

5 of 5 1.8 tip March 3, 2019
Reviewer: Kevin Montgomery from Farmington Hills, MI United States
Bought this to spray INSL-X Cabinet Coat paint.  Manufacturer recommends using a 1.8.   I did not have to thin the paint.
